    Automatic transfer V fold glue lamination hand towel and facial tissue paper making machine price

    Ask Lasest Price
    Brand Name : XINYUN
    Model Number : XY-GU-20A
    Certification : CE
    Price : 132000 usd per production line
    Payment Terms : T/T
    Supply Ability : 500 sets per year
    Delivery Time : 60-70 days
    • Product Details
    • Company Profile

    Automatic transfer V fold glue lamination hand towel and facial tissue paper making machine price

    Automatic transfer V fold glue lamination hand towel and facial tissue paper making machine price

    Automatic transfer V fold glue lamination hand towel and facial tissue paper making machine price

    No. Description Technical parameters
    1 Max. width of jumbo roll(mm) 1400
    2 Jumbo roll diameter(mm) <=¢1500
    3 Unwinding speed(m/min) <130
    4 Inner diameter of jumbo roll ¢76.3mm
    5 Machine structure Wall type and frame structure
    6 Weight of jumbo roll(T) Max.0.8
    7 Uncoiling system Sheet base belt paper feeding belt
    8 Alignment of jumbo roll Manual adjustment
    9 Unwind Mode Clockwise
    10 Paper threading method Manual
    11 Detection of paper break With a paper break detection system, the whole machine will stop when a paper break occurs, reducing the waste of raw paper
    12 Power 1.5KW
    13 Minimum air pressure requirement 0.6Mpa
    14 Gas consumption 1000 liters/shift
    15 Transfer mode of jumbo roll stands Independent motor to control
    Transmission
    16 Conveyor belt Flat belt drive
    17 Jumbo roll adjustment Screw drive
    17 Protection The main transmission components are protected by a protective cover

    Automatic transfer V fold glue lamination hand towel and facial tissue paper making machine price

    Feature and Functions:

    The paper-breaking knife roller adopts the structure of the spiral knife roller, which effectively solves the stability of the paper-breaking and the service life of the blade.

    The structure of the paper-breaking knife roller adopts the structure of the spiral knife roller from the original straight knife to the full-cutting type, and the spiral knife roller is the point-cutting type, which solves the instability of the paper break and the short life of the blade caused by the original straight knife structure.

    Automatic transfer V fold glue lamination hand towel and facial tissue paper making machine price

    Outline:

    Design Speed:100m/min

    Stable Speed:70-80m/min, or Max. number of long stacks: 6-10 long stacks/min(meet only one of them)

    Max.Width of jumbo roll:1400mm

    Daily Capacity:about 7.5T/22 hours (jumbo roll:three layers and 15g/m²)

    Jumbo roll paper:2-3 ply

    Raw Material of jumbo roll:straw paper,wood pulp paper,sugarcane pulp paper,bamboo pulp paper and so on

    Jumbo Roll Specification:2 ply:14-18g/m²/ply;3 ply: 13-15g/m²/ply

    Note: The above output calculation is for reference only. The specific production capacity is related to the base paper weight, base paper characteristics, product specifications and the specific conditions of each company.

    Automatic transfer V fold glue lamination hand towel and facial tissue paper making machine price

    Automatic transfer V fold glue lamination hand towel and facial tissue paper making machine price
    Automatic transfer V fold glue lamination hand towel and facial tissue paper making machine price
    Automatic transfer V fold glue lamination hand towel and facial tissue paper making machine price
    Automatic transfer V fold glue lamination hand towel and facial tissue paper making machine price
    Automatic transfer V fold glue lamination hand towel and facial tissue paper making machine price
    Q: Are you trading company or manufacturer
    A: We are factory.

    Q: How long is your delivery time?
    A: Generally it is 5-10 days if the goods are in stock. or it is 60-90 days if the goods are not in stock, it is according to
    quantity.

    Q: What is your terms of payment ?
    A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.

    After Sales Service

    (1), All our machine will have Two years guarantee
    (2), Within two year after receiving our machines, Under right operation and non-artificial reasons, If there are any damaged parts or accessories, We will replace them by DHL or Fedex immediately FREE OF CHARGE.
    (3), After two year warranty, Spare parts and damaged parts will be charged at cost price. If there is something wrong with the machine, We are responsible to solve this problem soonest, and help customers to restore production as soon as possible.

    (4), After the machines arrive, the sellers shall send technician to install the production line(if need). And the buyer shall pay their round-trip air tickets from China factory to buyer's factory, the charge of visa, food ,transportations and accommodation in buyer's city.

    Fujian Xinyun Machinery Development Co.,Ltd is good at Paper Converting Machinery Manufacture.
    Professional supplier of:

    1) Toilet Paper Machine (1.2m--2.8m width of parent roll, Customize Service)
    2) Roll Kitchen Paper Towel Machine (1.2m--2.8m width of parent roll, Customize Service)
    3) Facial Tissue Machine (2-14 output lanes)
    4) Napkin Paper machine(L-fold, 1/4-fold, 1/6-fold, 1/8-fold and other multi-fold type)
    5) Hand Towel Paper Machine(C-fold, V-fold and N/Z fold type)
    6) Pocket Tissue Machine(mini and standard size)
    7) All kinds of Tissue Paper Cutting and Packing Machine
    8) Another Household Paper Equipments and Production Line.
