    PLC Automatic Pocket Paper Tissue Machine Production Line 8-12bags/min

    Ask Lasest Price
    Brand Name : XINYUN
    Model Number : XY-NGU-21C
    Certification : CE
    Price : USD 53000 Set
    Payment Terms : T/T
    Delivery Time : Within 70 days after receipt of the deposit.
    • Product Details
    • Company Profile

    PLC Automatic Pocket Paper Tissue Machine Production Line 8-12bags/min

    XY-NGU-21C Best Price Automatic Pocket Paper Tissue Machine Production Line

    PLC Automatic Pocket Paper Tissue Machine Production Line 8-12bags/min

    Machines Including:

    Pocket tissue(handkerchief tissue) folding machine with separator

    Automatic pocket tissue (handkerchief tissue) packing machine

    Automatic pocket tissue(handkerchief tissue) wrapping machine


    Pocket tissue (handkerchief tissue) folding machine with separator

    PLC Automatic Pocket Paper Tissue Machine Production Line 8-12bags/min


    Main Technical Parameters:

    Speed of the separator

    60 bags/min

    Speed control

    Frequency converter

    Raw material

    13-25gm 1-3plies

    Outer Dia. of jumbo roll

    max. 1500mm

    Embossing unit

    single embossing (steel to rubber, stamp designed by user)

    Vacuum pump

    5.5Kw, 380V, 50Hz

    Production speed

    600PCS/min (controlled by frequency converter)

    Finished products unfold size

    210*210mm

    Finished products folded size

    102*52mm and 72*52mm

    Power

    0.75kw, 380v, 50Hz

    Overall size

    3851×650×1380mm(L×W×H)

    Over weight

    about 1T


    Automatic pocket tissue (handkerchief tissue) packing machine

    PLC Automatic Pocket Paper Tissue Machine Production Line 8-12bags/min


    Main Technical Parameters:

    Size of finished product: standard size

    L=102mm, W=52mm, H=22-26mm

    Mini size:L=72mm, W=52mm, H=22-26mm

    Packing size(L*W*H)

    (70-110)*(50-55)*(20-28)mm

    Machine speed

    105bags/min

    Stable speed

    90bags/min

    Heating power

    3.5Kw, 220V, 50Hz

    Drive power

    1.5Kw, 380V, 50Hz

    Air pressure

    0.6Mpa (user supplied)

    Step Motor

    0.38Kw, 380V, 50Hz

    Machine size

    2840*2650*1720mm (L*W*H)

    Machine weight

    1.5T


    Automatic pocket tissue (handkerchief tissue) wrapping machine (single channel)

    PLC Automatic Pocket Paper Tissue Machine Production Line 8-12bags/min


    Main Technical Parameters:

    Size of finished product

    5*2(standard size:260*102*44/52mm,mini size:260*72*44/52mm)

    Machine speed

    8-12bags/min

    Heating power

    1.78Kw, 380V, 50Hz

    Drive power

    1.5Kw, 380V, 50Hz

    Air pressure

    0.6Mpa (user supplied)

    Step Motor

    0.38Kw, 380V, 50Hz

    Machine weight

    1.4T

    Machine size

    2500*2350*1550mm (L*W*H)


    FAQ:
    Q: Are you trading company or manufacturer?
    A: We are factory.
    Q: How long is your delivery time?
    A: Generally it is 5-10 days if the goods are in stock. Or it is 60-90 days if the goods are not in stock, it is according to quantity.
    Q: Do you provide samples? Is it free or extra?
    A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
    Q: What is your terms of payment?
    A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
